How to install and operate the disc tipping machine in the organic fertilizer production line

• The tipper is in direct contact with materials during operation, which is highly corrosive. Therefore, the dirt stuck on the tipper, especially the dirt on the chassis, should be cleaned in time. If the protective paint falls off, it should be brushed again.
• Regularly check the tightness of the drive chain and adjust it in time. When the adjustment tension still fails to meet the requirements, remove several chains to make them meet the requirements; If it is found that the transmission chain links do not rotate smoothly, grease or engine oil shall be used for lubrication in time; The traveling bearing on the chassis, the mixing shaft rotating bearing (integrated with the upper part) and the lifting bearing should be regularly lubricated with grease.
• Before using the reducer, check whether there is oil in it, replace it with new oil after 100 hours of initial operation, and then replace it every 1000 hours, with an interval of one year.
• After the hydraulic system operates for 200 hours, all hydraulic oil shall be prevented and controlled, the impurities in the hydraulic system filter shall be removed, and the filter element shall be checked to see if it is necessary to replace; Whether to reuse the filtered hydraulic oil depends on the cleanliness of the drained hydraulic oil. When discharging the hydraulic oil, the cylinder rod shall be retracted back into the cylinder barrel; Clean the hydraulic system every 800 hours of operation.

It is applicable to the fermentation and turning of pig, cattle, sheep, chicken and other livestock manure, sludge garbage, filter mud of sugar factory, dregs, cakes, straw sawdust and other organic wastes, and is widely used in the fermentation and decomposition and water removal operations of organic fertilizer plants, compound fertilizer plants, sludge waste plants, horticultural farms, and bisporus cultivation plants.
Compared with the traditional trough type tipping machine, it greatly saves space. The dead angle tipping machine has wide tipping range, deep tipping depth, even tipping and high tipping efficiency.

High dumping depth: the dumping depth can reach 1.5-3 meters;
Large tipping span: the tipping width can reach 30m;
Low energy consumption for tipping: unique energy-saving transmission structure is adopted, which can reduce energy consumption by 70% compared with traditional organic fertilizer tipping equipment under the same workload
No dead angle for tipping: the wheel disc is symmetrically flipped, and there is no dead angle for tipping under the displacement of the speed regulating displacement trolley;
High degree of automation: equipped with fully automatic electrical control system, no personnel are required to operate the equipment during operation.
