Drum coating machinedrum coating machine

drum coating machine

In the process of fertilizer production, the granules are evenly wrapped with anti-caking agent or the granules are colored.

2022/12/19Organic fertilizer equipment Product 408

ColorBlue
materialNon woven fabric
Place of OriginChina

Inquiry By Whatsapp

Go To Amazon

Product parameters

FAQ

Product introduction

The cylinder coating machine is a device for coating powder or liquid on the surface of particles to realize the coating process. According to the process requirements, the equipment has a special design in the internal structure. It is an effective special coating equipment for fertilizers. The use of coating technology can effectively prevent the agglomeration of fertilizers and achieve the effect of slow release. The barrel coating machine is driven by the main motor to drive the belt and pulley, which is transmitted to the drive shaft through the reducer, and the split gear installed on the drive shaft meshes with the large ring gear fixed on the machine body, and rotates in the opposite direction. The material is fed from the feed end, and can be discharged from the discharge end after being mixed inside the cylinder, thus realizing continuous production.

Product structure

Bracket part: The bracket part includes a front bracket and a rear bracket, which are fixed on the corresponding foundation and used to support the cylinder for positioning and rotation. The front and rear brackets are all composed of a bracket, a supporting wheel frame and a supporting wheel. During installation, the height and angle of the equipment can be adjusted by adjusting the distance between the two supporting wheels on the front and rear brackets. Transmission part: The transmission part provides the required power for the normal operation of the entire coating machine. Its components include a transmission frame, a motor, a triangular belt transmission mechanism, a reducer and a gear transmission mechanism, etc., among which the reducer and the gear are connected by a direct connection or a coupling to transmit the drive according to the load.

Cylinder: The cylinder is the working part of the whole coating machine. There are rolling belts for support and gear rings for transmission on the outside, and baffles are welded inside to guide the material to flow slowly and make it evenly coated. Coating part: Use a powder duster or a coating agent to coat the particles.

The main technical parameters

Specifications	Inner diameter（mm）	Length（mm）	Inclination	Rotating speed（r/min）	Capacity（t/h）	Power（kw）
BM1003	1000	3000	3	17.4	2-3	4
BM1204	1200	4000	3	14	3-5	5.5
BM1404	1400	4000	3	13	5-7	7.5
BM1606	1600	6000	3	12	7-15	11
BM1808	1800	8000	3	12	15-30	15
BM2010	2000	1000	3	12	30-45	22

The main technical parameters

What fertilizer equipment does Hongxin Environmental Protection Company produce?

Tai’an Hongxin Environmental Protection Technology Co., Ltd. is located at the foot of Mount Tai, Tai’an High-tech Development Zone (East Zone), covering an area of 40000 ㎡, a building area of 16000 ㎡, and a total asset of 68 million yuan. It is currently an enterprise with A2 (Class I, II, III) pressure vessel design and manufacturing licenses, and is also a professional manufacturer of chemical equipment in Shandong Province, At the same time, it is a well-known professional manufacturer in the country (compound fertilizer equipment, organic fertilizer equipment, complete set of synthetic ammonia equipment, slow and controlled release fertilizer equipment, coal slurry dryer, BB fertilizer equipment, ammonia granulation, liquid ammonia storage tank, compound fertilizer ammonia station, dryer, pressure vessel, organic fertilizer production line, compound fertilizer production line, BB fertilizer production line)

What are the company’s main production line equipment and products?

The company has more than 100 sets of professional processing equipment such as CAD design center, steel casting branch, large gear processing equipment, large lathe, etc. It has a team of high-quality process engineers and professional equipment installation technicians. The company provides users with technical consultation, process design, installation, commissioning, personnel training, turnkey project and other one-stop services, and guarantees perfect after-sales service in the later stage.

Compound fertilizer equipment production lineCompound fertilizer equipment is a kind of equipment for making fertilizer by ammonia acid and ammonia spray granulation.

Organic fertilizer equipment production lineOrganic fertilizer production must go through fermentation Crush Mixing Granulation dry. Cooling The process of screening

Controlled release fertilizer equipmentControlled release fertilizer is an advanced form of slow-release fertilizer.

Flushing and fertilizing equipmentAs a kind of quick-acting fertilizer, washing fertilizer has comprehensive nutrient elements

Comprehensive strength of the company’s production?

Design and manufacture of Class I, II and III pressure vessels.
Design, manufacture and installation of complete set of synthetic ammonia equipment.
200000-300000 tons automatic batching BB fertilizer production line
200000-300000 t/a urea base, ammonia acid granulation and compound fertilizer production line
1-20 million tons/year organic and inorganic fertilizers, garbage, sludge and other organic waste harmless treatment fertilizer equipment
National patent 1-20 million tons/year controlled-release coated fertilizer process and equipment (patent No. 20072021844. X)
National patent: 200000t/a domestic and paper sludge; Monosodium glutamate black liquor spray drying fertilizer equipment (patent No. ZL20072021843.5)

Business scope of the company?

Our products are sold all over the country and exported to more than 20 countries and regions such as the United Arab Emirates, Indonesia, Vietnam, Bangladesh, South Korea, Japan, Myanmar, South Korea, Nigeria and Australia.
