Chain conveyor

The chain plate conveyor is a transmission device with a standard chain plate as the bearing surface and a motor reducer as the power transmission.

2022/12/19Compound fertilizer equipment Product 379

ColorBlue
materialAluminum profiles, ordinary carbon steel, stainless steel
power partchain, transmission plate
Place of OriginChina

Inquiry By Whatsapp

Go To Amazon

Product parameters

FAQ

Product introduction

The chain plate conveyor is a transmission device with a standard chain plate as the bearing surface and a motor reducer as the power transmission. Chain plate conveyor consists of power unit (motor), transmission shaft, roller, tensioning device, sprocket, chain, bearing, lubricant, chain plate and so on. Among them, the main two parts that drive the transportation of materials are: the chain, which uses its reciprocating motion to provide traction power; the metal plate, which is used as the carrier during the transportation process. Multiple rows of chain plates can be used in parallel to make the chain conveyor very wide and form a differential speed. Using the speed difference of multiple rows of chain plates, the multi-row conveying can be changed into single-row conveying without extrusion, so as to meet the beverage labeling requirements. To meet the requirements of single-row conveying of equipment such as filling, cleaning, etc., we can make the head and tail of the two chain conveyors into an overlapping mixed chain so that the bottle (can) body is in a dynamic transition state, so that no material remains on the conveying line , It can meet the pressure and pressure-free delivery of empty bottles and full bottles.

working principle

Chain plate conveyor is composed of power unit (motor), transmission shaft, roller, tensioning device, sprocket, chain, bearing, lubricant, chain plate and so on. Among them, the main two parts that drive the transportation of materials are: the chain, which uses its reciprocating motion to provide traction power; the metal plate, which is used as the carrier during the transportation process. Its principle is mainly to use a series of chains fixed on the traction chain to provide traction, and use metal plates as the carrier to guide the material to be conveyed along the horizontal or inclined direction. Chain plate conveyors are widely used in various industries, such as electric power, metallurgy, brewing, chemical industry, medical treatment, machinery manufacturing and other broad fields. In order to meet the various needs of the production site, we can specifically design the conveying machines in the automation line to meet the requirements and purposes.

Features

1. The conveying surface of the chain-plate conveyor is flat and smooth, with low friction, and the transition of materials between conveying lines is smooth. It can convey all kinds of glass bottles, PET bottles, cans and other materials, and can also convey all kinds of bags ;

2. The chain plates are made of stainless steel and engineering plastics and have a wide variety of specifications, which can be selected according to the conveying materials and process requirements, and can meet the different needs of all walks of life;

3. The frame material is divided into aluminum profile, ordinary carbon steel and stainless steel.

4. Large conveying capacity, can carry large loads, such as for electric vehicles, motorcycles, generators and other industries;

5. The conveying speed is accurate and stable, which can ensure accurate synchronous conveying;

6. Chain conveyors can generally be directly washed with water or soaked in water. The equipment is easy to clean and can meet the hygienic requirements of the food and beverage industries;

7. The equipment layout is flexible. Horizontal, inclined and turning conveying can be completed on one conveying line;

8. The equipment is simple in structure and easy to maintain.

Main technical parameters

Model	FMS25	FMS32	FMS40	FMS50	FMS63	FMS80
Slot width(mm)	250	315	400	500	630	800
Loading depth(mm)	250	315	400	500	500	500
Rated Conveying Capacity(t/h)	5/10	8/15	15/20	18/30	35/50	45/60
Maximum conveying distance(m)	50	50	50	50	50	50
Running speed(m/s)	0.16/0.20	0.16/0.20	0.16/0.22	0.16/0.22	0.20/0.30	0.20/0.30

Chain conveyor Main technical parameters

What fertilizer equipment does Hongxin Environmental Protection Company produce?

Tai’an Hongxin Environmental Protection Technology Co., Ltd. is located at the foot of Mount Tai, Tai’an High-tech Development Zone (East Zone), covering an area of 40000 ㎡, a building area of 16000 ㎡, and a total asset of 68 million yuan. It is currently an enterprise with A2 (Class I, II, III) pressure vessel design and manufacturing licenses, and is also a professional manufacturer of chemical equipment in Shandong Province, At the same time, it is a well-known professional manufacturer in the country (compound fertilizer equipment, organic fertilizer equipment, complete set of synthetic ammonia equipment, slow and controlled release fertilizer equipment, coal slurry dryer, BB fertilizer equipment, ammonia granulation, liquid ammonia storage tank, compound fertilizer ammonia station, dryer, pressure vessel, organic fertilizer production line, compound fertilizer production line, BB fertilizer production line)

What are the company’s main production line equipment and products?

The company has more than 100 sets of professional processing equipment such as CAD design center, steel casting branch, large gear processing equipment, large lathe, etc. It has a team of high-quality process engineers and professional equipment installation technicians. The company provides users with technical consultation, process design, installation, commissioning, personnel training, turnkey project and other one-stop services, and guarantees perfect after-sales service in the later stage.

Compound fertilizer equipment production lineCompound fertilizer equipment is a kind of equipment for making fertilizer by ammonia acid and ammonia spray granulation.

Organic fertilizer equipment production lineOrganic fertilizer production must go through fermentation Crush Mixing Granulation dry. Cooling The process of screening

Controlled release fertilizer equipmentControlled release fertilizer is an advanced form of slow-release fertilizer.

Flushing and fertilizing equipmentAs a kind of quick-acting fertilizer, washing fertilizer has comprehensive nutrient elements

Comprehensive strength of the company’s production?

Design and manufacture of Class I, II and III pressure vessels.
Design, manufacture and installation of complete set of synthetic ammonia equipment.
200000-300000 tons automatic batching BB fertilizer production line
200000-300000 t/a urea base, ammonia acid granulation and compound fertilizer production line
1-20 million tons/year organic and inorganic fertilizers, garbage, sludge and other organic waste harmless treatment fertilizer equipment
National patent 1-20 million tons/year controlled-release coated fertilizer process and equipment (patent No. 20072021844. X)
National patent: 200000t/a domestic and paper sludge; Monosodium glutamate black liquor spray drying fertilizer equipment (patent No. ZL20072021843.5)

Business scope of the company?

Our products are sold all over the country and exported to more than 20 countries and regions such as the United Arab Emirates, Indonesia, Vietnam, Bangladesh, South Korea, Japan, Myanmar, South Korea, Nigeria and Australia.
